Sinotruk Howo 4x2 5.5cbm Sweeper Truck
v1v2v3v4v5
Complete Truck · Road Sweeper

Sinotruk Howo 4x2 5.5cbm Sweeper Truck

  • Chassis BrandHowo
  • Rated Power116 hp
  • Engine ModelYN4102QBZL
  • Emission StandardEuro 3
  • Driving Type4x2, LHD
  • Total Mass7360 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: SW-5500

Overview

About this truck

The Sinotruk Howo 4x2 sweeper truck is built on the reliable Howo ZZ1047D3414 chassis with a 116 hp Euro 3 diesel engine and 6-speed manual transmission. It features a 1500 L water tank and 4 cbm dust bin, delivering a maximum cleaning capacity of 45000 m²/h with 95% efficiency. With a 2.8 m cleaning width and 120 mm maximum suction particle size, it is suitable for urban road sweeping and maintenance. The truck comes with a single-row cabin with A/C, 7.00R16 tyres, and is certified to CCC standards.

Specifications

Technical parameters

Chassis BrandHowo
Chassis ModelZZ1047D3414
Driving Type4x2, LHD
Wheelbase3360 mm
Engine ModelYN4102QBZL
Rated Power116 hp
Emission StandardEuro 3
Fuel TypeDiesel
Gearbox6-speed manual
Tyre7.00R16
CabinSingle row, A/C
Total Mass7360 kg
Kerb Weight5450 kg
Rated Payload1910 kg
Dimension (L×W×H)6200x2000x2550 mm
Max Speed95 km/h
Clean Width2.8 m
Water Tank Capacity1500 L
Dust Bin Capacity4 cbm
Auxiliary EngineJE493/87hp
Max Clean Capacity45000 m²/h
Cleaning Efficiency95%
Clean Speed5-20 km/h
Maximum Suction Particle Size120 mm
FunctionsSweeping
ConditionNew
Warranty1 Year
