16000L Dongfeng Street Sweeper Truck with High Pressure Cleaning
v1v2v3v4v5v6v7v8
Complete Truck · Road Sweeper

16000L Dongfeng Street Sweeper Truck with High Pressure Cleaning

  • Chassis ModelDFL1160BX3
  • Engine190hp CUMMINS
  • Emission StandardEu 3
  • Gross Weight Vehicle18,000 Kg
  • Water Tank Capacity9000 Liters
  • Max Clean Capacity70000 M2/h

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 47838036

Overview

About this truck

The 18000kg Street Sweeper Truck is an advanced diesel-fueled vehicle that combines high-pressure water spraying with mechanical sweeping and suction capabilities. This truck-mounted street sweeper features two center-mounted brushes equipped with V-shaped high-pressure water spray rods positioned ahead of the brushes, along with a center-mounted suction nozzle containing integrated high-pressure water jets. During operation, the system sprays pressurized water to dislodge stubborn road surface debris, then simultaneously suction-collects water and waste into the garbage bin. The vehicle includes a 17-meter high-pressure water flushing reel and manual water gun for enhanced convenience and efficiency. Its substantial water tank capacity supports extended operations for urban roads, highways, squares, airports, docks, tunnels, bridges, and curb cleaning. The design incorporates German engineering components throughout, delivering reliable mechanized cleaning, dust suppression, and comprehensive road maintenance solutions suitable for highways and municipal infrastructure.

Specifications

Technical parameters

Drive Model4x2
Gross Weight Vehicle18,000 Kg
Dumping MethodRear Dump
Transmission6 Gears
Water Tank Capacity9000 Liters
Dust Tank7000 Liters
Curb Weight11,350 Kg
Fuel TypeDiesel
Engine190hp CUMMINS
Clean Speed3-20 Km/h
Clean Width3.5m
Water Pump Flow154 L/min
Cleaning Efficiency>=95%
Maximum Suction Particle Size110 Mm
Disc Brush Size>=400 Mm
Max Clean Capacity70000 M2/h
Dump Bin Tilting Angle>=46 deg
Discharge Door Opening Angle>=85 deg
Hydraulic System Pressure16 MPa
Hyraulic Oil Tank60 L
Brush Diameter850 Mm
High Pressure PumpGermany PT36
Chassis ModelDFL1160BX3
Wheelbase5000mm
Front Suspension1430 mm
Rear Suspension2150 mm
Chassis EngineB190-33
Engine Power140kw, 5900cc, 190hp
Spare Engine Power155 kW
Max Upgrade Angle30%
Emission StandardEu 3
Accelerating Outside Noise<=84dB(A)
Max Speed103 km/h
Approach Angle20 deg
Departure Angle13 deg
Kerb Weight11350 kg
Whole Weight16000kg
Whole Dimension8580x2490x3100mm
Minimum Height Above Ground230 mm
Electrical System ModelDC24 V
Voltage24 V
Hydraulic System ModelOpen, electrical control
Brush Angle Tilt Forward4-6 degrees
Brush Angle Tilt4-7 degrees
Suction Plate Diameter180 mm
High Pressure Pump ModelGermany PT36
High Pressure Pump Speed1150 r/min
System Pressure Water10 MPa
Water Valve ModelHydraulic pressure ball valve
Water Valve Pressure7 MPa
