4T Dongfeng Euro3 Flatbed Wrecker One-Tow-Two Underlift
v1v2v3
Complete Truck · Flatbed

4T Dongfeng Euro3 Flatbed Wrecker One-Tow-Two Underlift

  • Chassis Manufacturer/ModelDongfeng
  • Rated Power120hp
  • Engine Manufacturer/ModelYuChai
  • Emission StandardEuro 3
  • Driving Type4x2 left hand drive
  • Total Mass10495 Kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 48207118

Overview

About this truck

The 4-ton Dongfeng flatbed wrecker truck features steel construction with configurable deck lengths and widths, offering different structural capacities for enhanced job site strength and durability. Available with multiple chassis options including ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, and IVECO brands, this truck supports Euro 2, 3, 5, and 6 emissions standards. It accommodates both right-hand and left-hand drive configurations with 4x2 or 4x4 driving types. Key features include a 5.6-meter bed with 4-ton capacity, optional hitch ball and remote control functionality, and customizable platform materials such as Q235B, Q345, G70, NM500, and Hardox 450.

Specifications

Technical parameters

Product NameFlatbed Wrecker Truck
ConditionNew
Underlift2 Sections, 3 Tons
OperationBoth Sides Manual
Warranty1 Year
Highlight4T Flatbed Wrecker Truck, 4T flatbed towing truck, Two Carrier Flatbed Wrecker Truck
Dimensions (L X W X H)7600x2350x2600mm
Main Winch4 Tons
Underlift Tow Rating6 Tons
Remote ControlOptional
Bed Dimension5600x2350mm
Overall Dimension7600x2350x2600(mm)
Total Mass10495 Kg
Rated Payload5000 Kg
Kerb Weight5495 Kg
Passenger Capacity3
Chassis Manufacturer/ModelDongfeng
Driving Type4x2 left hand drive
Wheel Base3800 mm
GearboxFive speed forward and one reverse, manual
Front/Rear Track1835/1640(mm)
Tyre7.50R16
Number of Tyres6+1(spare tyre)
Front/Rear Suspension1180/1715(mm)
Leaf Spring Number11/9+7
FeaturesAC, Air Brake, Power Steer, Central Locking, Power Windows
Engine Manufacturer/ModelYuChai
Rated Power120hp
Fuel TypeDiesel oil
Displacement/Capacity3856ml
Emission StandardEuro 3
CylinderStraight/4/intercooling
Max. Torque450N.m
Velocity2500rpm
ColorCustomizable, electrophoresis painting optional (extra USD400)
Winch Capacity4 tons
Lift Capacity4 tons
Extension Capacity4 tons
Platform MaterialQ235B, 4mm thick
Platform TypeCheckered
Platform Dimension5600 x 2300 mm (customizable)
Wireless Remote ControlOptional
Subframe with UnderliftMatch to chassis
Siren Long Lamp with Speaker1 pcs
Sides Lights8 pcs
Frame Lights with Lights Seat6 pcs
Bed Extension Cylinder with Seat1 pcs
Bed Lift Cylinder with Seat2 pcs
Underlift lift Cylinder2 pcs
Underlift Extension Cylinder1 pcs
Hydraulic Winch1 pcs
Hydraulic Pump1 pcs
Hydraulic Multi Way Valve1 pcs
Hydraulic Balance Valve2 pcs (1 for lift and 1 for underlift)
Hydraulic Hose1 set
Hydraulic Hose Containment1 set
Hose Sleeve1 pcs
Manual Control with Stainless Steel Seat2 sets (on both sides)
Oil Tank1 pcs
Auxiliary Wheels2 pcs
Straps4 pcs
Toolbox2 pcs
Wheel Grids2 pcs
L arms2 pcs
Fence2 pcs
Mudflap2 pcs
Lamp Frame1 pcs
Tow Chain1 pcs
Frame and Lights Bolts1 set
Toolbox and Fence Brackets Square Tube1 set
