Dongfeng 1T Light Cargo Fence Lorry
v1v2v3v4v5v6v7
Complete Truck · Cargo

Dongfeng 1T Light Cargo Fence Lorry

  • ChassisDongfeng
  • Rated Power42kw/57hp
  • EngineQC490
  • Emission StandardEu 2
  • Driving Type4x2
  • Total Mass3350 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50544450

Overview

About this truck

Freight trucks like this cargo vehicle are designed primarily for transporting goods. This category encompasses dump trucks, tractor trucks, off-road trucks for off-highway and roadless areas, and various vehicles specially manufactured for special needs. The Dongfeng model features a 57-horsepower diesel engine and can handle loads up to 1.5 tons. Most trucks in this class rely on diesel power, though some lighter variants use gasoline, petroleum gas, or natural gas alternatives. This particular lorry truck combines practical hauling capacity with fence-sided cargo containment for secure transport of goods.

Specifications

Technical parameters

Model NumberCL1043
ChassisDongfeng
ColorOption
Loading Capacity1-2 Tons
EngineQC490
Front Axles Loading1500 KG
Rear Axles Loading3000 KG
Spring3/5
Wheelbase2800mm
GearMG516
Tire185R15 8PR
Name1 ton Cargo Truck
Dimension(LxWxH)5490x2000x2450 mm
Total Mass3350 kg
Rated Payload1500 kg
Kerb Weight1850 kg
Passenger3
Approach/Departure Angle23°/13 °
Manufacture/ModelCL1043
Driving Type4x2
Wheel Base2800 mm
GearboxMG516
Front/Rear Track1450/1550 mm
Tyre model185R15 8PR
The Number of Tyre6+1 (spare tyre)
Front/Rear Suspension1120/2095 mm
Axles LoadingFront 1.5 T Rear  3.5 T
Oil Tank90L Iron
Manufacturer/ModelQUANCHAI/ QC490
Rated Power42kw/57hp
Fuel TypeDiesel oil
Displacement/Capacity2540 ml
Emission StandardEu 2
Cylinder4
Max. Torque/ speed210N.m/ 1500-2900rpm
Velocity2900 rpm
Color/LogoCustomized
Rear bucket3500x2000x500 mm
Dump functionoption
