Isuzu KV100 115hp Cargo Fence 2-3T
v1v2v3v4v5v6
Complete Truck · Cargo

Isuzu KV100 115hp Cargo Fence 2-3T

  • Chassis Manufacturer/ModelQL1044AMHAY
  • Engine Manufacturer/ModelISUZU/4KH1CN5MD
  • Emission StandardEU5
  • Driving Type4x2
  • Total Mass6350 kg
  • Oil Tank200L Iron

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50410806

Overview

About this truck

The Isuzu KV100 is a light cargo fence truck designed for general freight transportation. Powered by a 115-horsepower diesel engine, it features a 3-ton rated payload capacity and accommodates three passengers. The vehicle measures 5,990 x 2,200 x 2,750 mm with a total mass of 6,350 kg and kerb weight of 3,350 kg. It utilizes a 4x2 driving configuration with a 3,360 mm wheelbase. The truck includes a rear cargo bed measuring 4,000 x 2,000 x 500 mm and offers optional dump functionality. Built to EU5 emission standards, it delivers maximum torque of 290 N.m at 1,500-2,900 rpm.

Specifications

Technical parameters

Model NumberQL1040BUHAY
Chassis Manufacturer/ModelQL1044AMHAY
Engine Manufacturer/ModelISUZU/4KH1CN5MD
Engine Power85kw/115hp
Displacement2999 ml
Fuel TypeDiesel oil
Emission StandardEU5
Cylinders4
Max Torque/Speed290N.m/1500-2900rpm
Dimension (LxWxH)5990x2200x2750 mm
Total Mass6350 kg
Rated Payload3000 kg
Kerb Weight3350 kg
Passengers3
Approach/Departure Angle23/13 deg
Driving Type4x2
Wheelbase3360 mm
GearboxMSB5
Front/Rear Track1640/1655 mm
Tyre Model7.00R16
Number of Tyres6+1 (spare)
Front/Rear Suspension1120/2095 mm
Axles LoadingFront 2T/Rear 4T
Oil Tank200L Iron
Rear Bucket Dimensions4000x2000x500 mm
Dump FunctionOptional
