Isuzu KV100 115hp Cargo Box Van 2-3T
v1v2v3v4v5v6v7
Complete Truck · Cargo

Isuzu KV100 115hp Cargo Box Van 2-3T

  • Chassis Manufacture/ModelQL1044AMHAY
  • Rated Power85kw/115hp
  • Engine Manufacturer/ModelISUZU/4KH1CN5MD
  • Emission StandardEU 5
  • Driving Type4x2
  • Total Mass6350 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50544469

Overview

About this truck

Freight trucks like this cargo vehicle serve general transportation purposes, including hauling goods across various terrains. This particular model represents the category of commercial vehicles designed primarily for moving merchandise. The truck features a diesel engine powering a four-wheel-drive configuration suitable for both highway and off-road applications. Vehicles can be classified into two types based on their weight: heavy and light. Most freight trucks in this class utilize diesel propulsion, though alternatives exist using gasoline or natural gas variants.

Specifications

Technical parameters

Model NumberQL1040BUHAY
Chassis Manufacture/ModelQL1044AMHAY
Driving Type4x2
Wheel Base3360 mm
GearboxMSB5
Front/Rear Track1640/1655 mm
Tyre Model7.00R16
Number of Tyres6+1 (spare)
Front/Rear Suspension1120/2095 mm
Axles LoadingFront 2T, Rear 4T
Oil Tank200L Iron
Engine Manufacturer/ModelISUZU/4KH1CN5MD
Rated Power85kw/115hp
Fuel TypeDiesel oil
Displacement/Capacity2999 ml
Emission StandardEU 5
Cylinders4
Max Torque/Speed290N.m/1500-2900rpm
Velocity2900 rpm
Dimension (LxWxH)5990x2200x2750 mm
Total Mass6350 kg
Rated Payload3000 kg
Kerb Weight3350 kg
Passengers3
Approach/Departure Angle23/13 degrees
Rear Bucket4000x2000x2000 mm
Dump FunctionOptional
Color/LogoCustomized
