Isuzu 100P Cargo Fence 2-3T
v1v2v3v4v5v6
Complete Truck · Cargo

Isuzu 100P Cargo Fence 2-3T

  • Rated Power88kw/120hp
  • Emission StandardEu 6
  • Driving Type4x2
  • Total Mass6350 kg
  • Oil Tank200L Iron
  • Displacement/Capacity2999 ml

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50410802

Overview

About this truck

Freight trucks, generally referred to as cargo trucks or trucks, include dump trucks, tractor trucks, off-road trucks in off-highway and roadless areas, and various vehicles specially manufactured for special needs. These vehicles are primarily engineered for transporting goods and can sometimes tow other vehicles as part of the commercial vehicle category. Most trucks utilize diesel engines, though some lighter models may use gasoline, petroleum gas, or natural gas as alternative fuels. This particular model is an ISUZU 100P light cargo fence truck with 120 horsepower capability and a 2-ton loading capacity. The truck features a 4x2 driving configuration with a total mass of 6,350 kg and a rated payload of 3,000 kg. Its dimensions measure 5990 x 2200 x 2750 mm, accommodating three passengers.

Specifications

Technical parameters

Model NumberQL1040BUHAY
Name2 tons Isuzu Cargo Truck
Dimension (LxWxH)5990x2200x2750 mm
Total Mass6350 kg
Rated Payload3000 kg
Kerb Weight3350 kg
Passenger3
Approach/Departure Angle23°/13°
Manufacture/ModelQL1040BUHAY
Driving Type4x2
Wheel Base3360 mm
GearboxMSB5
Front/Rear Track1640/1655 mm
Tyre model7.00R16
The Number of Tyre6+1 (spare tyre)
Front/Rear Suspension1120/2095 mm
Axles LoadingFront Man 2 T Rear Man 4 T
Oil Tank200L Iron
Manufacturer/ModelISUZU/ 4KH1CN6LB
Rated Power88kw/120hp
Fuel TypeDiesel oil
Displacement/Capacity2999 ml
Emission StandardEu 6
Cylinder4
Max. Torque/speed290N.m/ 1500-2900rpm
Velocity2900 rpm
Color/LogoCustomized
Rear bucket3500x2000x500 mm
Dump functionoption
