Isuzu KV100 115hp Tarpaulin Cargo Box Van 2-3T
v1v2v3v4v5v6v7
Complete Truck · Cargo

Isuzu KV100 115hp Tarpaulin Cargo Box Van 2-3T

  • Rated Power85kw/115hp
  • Manufacturer/Model (Engine)ISUZU/4KH1CN5MD
  • Emission StandardEU 5
  • Driving Type4x2
  • Total Mass6350 kg
  • Oil Tank200L Iron

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50544484

Overview

About this truck

Freight trucks, commonly called cargo trucks, encompass dump trucks, tractor trucks, and off-road vehicles designed for special transportation needs. These commercial vehicles primarily transport goods and can tow other vehicles. Most trucks use diesel engines, though some lighter models may use gasoline, petroleum gas, or natural gas. The ISUZU KV100 Tarpaulin truck features a 115hp engine and is designed as a 2-3 ton cargo box van with fence truck capabilities. It represents a light cargo solution for general freight transportation.

Specifications

Technical parameters

Model NumberQL1040BUHAY
Name3 tons Isuzu Tarpaulin Truck
Dimension (LxWxH)5990x2200x2750 mm
Total Mass6350 kg
Rated Payload3000 kg
Kerb Weight3350 kg
Passenger3
Approach/Departure Angle23°/13°
Manufacture/ModelQL1044AMHAY
Driving Type4x2
Wheel Base3360 mm
GearboxMSB5
Front/Rear Track1640/1655 mm
Tyre model7.00R16
Number of Tyre6+1 (spare tyre)
Front/Rear Suspension1120/2095 mm
Axles LoadingFront Man 2 T Rear Man 4 T
Oil Tank200L Iron
Manufacturer/Model (Engine)ISUZU/4KH1CN5MD
Rated Power85kw/115hp
Fuel TypeDiesel oil
Displacement/Capacity2999 ml
Emission StandardEU 5
Cylinder4
Max. Torque/speed290N.m/1500-2900rpm
Velocity2900 rpm
Color/LogoCustomized
Rear bucket4000x2000x2000 mm
Dump functionoption
