Sinotruk Howo 4x2 10cbm Street Sweeper Truck
v1v2v3v4v5v6
Complete Truck · Road Sweeper

Sinotruk Howo 4x2 10cbm Street Sweeper Truck

  • Chassis BrandSinotruk
  • Rated Power160 hp
  • Engine ModelYuchai YC4E160-33
  • Emission StandardEuro 2
  • Driving Type4x2, LHD / RHD optional
  • Total Mass16000 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: SW-10HW

Overview

About this truck

The Sinotruk Howo 4x2 street sweeper combines sweeping, washing and dust suppression in one unit, making it suitable for urban road cleaning and construction site maintenance. It is built on a reliable Howo chassis with a Yuchai 160 hp engine and a 10-speed manual gearbox, offering stable performance and easy operation. The vehicle features a 3000 L water tank and a 7 m³ dust bin, with a maximum cleaning capacity of 70000 m²/h and a cleaning efficiency of 95%. It is available in LHD or RHD configurations and comes with a 1-year warranty.

Specifications

Technical parameters

Chassis BrandSinotruk
Chassis ModelZZ1107G4515C
Driving Type4x2, LHD / RHD optional
Wheelbase4500 mm
Engine ModelYuchai YC4E160-33
Rated Power160 hp
Emission StandardEuro 2
Fuel TypeDiesel
Gearbox10-speed manual
Tyre8.25R20
CabinOne-and-half row, A/C
Total Mass16000 kg
Kerb Weight9800 kg
Rated Payload6200 kg
Dimension (L×W×H)7810×2500×3100 mm
Max Speed95 km/h
Clean Width3.2 m
Water Tank Capacity3000 L
Dust Bin Capacity7 m³
Auxiliary EngineCUMMINS 140 hp
Max Clean Capacity70000 m²/h
Cleaning Efficiency95%
Clean Speed3-20 km/h
Brush Diameter850 mm
Maximum Suction Particle Size2 inches
FunctionsSweeping + Washing + Dust suppression
ConditionNew
Warranty1 Year
