EU6 DFAC Road Sweeping Truck with High Pressure Cleaner
v1v2v3v4v5v6
Complete Truck · Road Sweeper

EU6 DFAC Road Sweeping Truck with High Pressure Cleaner

  • Chassis ModelEQ1125SJ8CDC
  • Engine Power150hp to 170hp
  • Emission StandardEURO 6
  • Driving Type4x2
  • Gross Vehicle Weight11995 kg
  • Water Tank Volume4 m3

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 47812227

Overview

About this truck

This street cleaning truck merges road sweeping with high-pressure washing capabilities. It features two center-mounted brushes equipped with V-shaped high-pressure water spray rods positioned ahead of the brushes, plus a center-mounted suction nozzle containing integrated high-pressure spray mechanisms. During operation, the vehicle sprays pressurized water to dislodge road surface debris, with water and refuse collected into the waste bin via suction. The truck includes a 17-meter high-pressure water flushing reel and gun for efficient cleaning of urban roads, highways, squares, airports, docks, tunnels, bridges, and barrier walls. It suits mechanized street cleaning, sweeping, spray dust suppression, and related urban maintenance operations.

Specifications

Technical parameters

ConditionNew
Emission StandardEURO 6
Transmission TypeManual
Fuel TypeDiesel
Dimensions (L X W X H)7000x2300x2700 mm
Gross Vehicle Weight11995 kg
Driving Type4x2
Engine Power150hp to 170hp
Engine ModelYCY30165-60
Chassis ModelEQ1125SJ8CDC
Wheelbase3800 mm
Front Suspension1130 mm
Rear Suspension2070 mm
Curb Weight7045 kg
Whole Weight11995 kg
Max Speed100 km/h
Max Upgrade Angle30%
Approach Angle20 degrees
Departure Angle11 degrees
Minimum Height Above Ground250 mm
Water Tank Volume4 m3
Dust Tank Volume5 m3
Clean Speed3-20 km/h
Clean Width3 m
Water Pressure12 MPa
Water Pump Flow115 L/min
Cleaning Efficiency>=95%
Maximum Suction Particle Size110 mm
Max Clean Capacity60000 m2/h
Disc Brush Size>=400 mm
Hydraulic System Pressure16 MPa
Oil Tank60 L
Oil Temperature60 degrees C
Electrical System VoltageDC 24 V
Battery24 V
Brush Diameter850 mm
Brush Angle Forward Tilt4-6 degrees
Brush Angle Side Tilt4-7 degrees
Suction Plate Diameter180 mm
Suction Plate Width1800 mm
High Pressure Pump ModelPT36
System Pressure (Water)10 MPa
Pump Speed1150 r/min
Water Valve Pressure7 MPa
