Foton 4x2 5.5CBM Sweeper Truck
v1v2v3v4v5
Complete Truck · Road Sweeper

Foton 4x2 5.5CBM Sweeper Truck

  • Chassis BrandFoton
  • Rated Power148 hp
  • Engine ModelISF2.8s3148T
  • Emission StandardEuro 3
  • Driving Type4x2, LHD
  • Total Mass7360 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: FT-SW-5500

Overview

About this truck

The Foton 4x2 sweeper truck is built on a reliable BJ1088 chassis with a 148 hp diesel engine and 5-speed manual gearbox. It features a 2500 L water tank and 3 m³ dust bin, delivering a maximum cleaning capacity of 60000 m²/h with 95% efficiency. Ideal for municipal and industrial road cleaning, it offers a cleaning width of 2.8-3.0 m and a maximum suction particle size of 120 mm.

Specifications

Technical parameters

Chassis BrandFoton
Chassis ModelBJ1088
Driving Type4x2, LHD
Wheelbase3360 mm
Engine ModelISF2.8s3148T
Rated Power148 hp
Emission StandardEuro 3
Fuel TypeDiesel
Gearbox5-speed manual
Tyre7.00R16
CabinSingle row, A/C
Total Mass7360 kg
Kerb Weight5100 kg
Rated Payload2260 kg
Dimension (L×W×H)6200×2000×2550 mm
Max Speed95 km/h
Clean Width2.8-3.0 m
Water Tank Capacity2500 L
Dust Bin Capacity3 m³
Auxiliary Engine87 hp
Max Clean Capacity60000 m²/h
Cleaning Efficiency95%
Clean Speed3-20 km/h
Maximum Suction Particle Size120 mm
FunctionsSweeping
ConditionNew
Warranty1 Year
