JAC Cargo Van 2T
v1v2v3v4v5v6v7
Complete Truck · Cargo

JAC Cargo Van 2T

  • ChassisJAC
  • Rated Power68kw/92hp
  • EngineHFC4DA1-1
  • Emission StandardEU 2
  • Driving Type4x2
  • Total Mass6350 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50544457

Overview

About this truck

The JAC cargo truck is a commercial freight vehicle designed for transporting goods. These trucks are classified as commercial vehicles and typically feature diesel engines, though some lighter models may use alternative fuels. The 92hp EU 2 engine model represents a cargo solution with 3-ton capacity. Freight trucks in this category include various specialized vehicles adapted for specific transportation needs across both highway and off-road applications.

Specifications

Technical parameters

Model NumberHFC1042L3K
ChassisJAC
ColorOption
Loading Capacity2-3 Tons
EngineHFC4DA1-1
Front Axles Loading1500 KG
Rear Axles Loading3000 KG
TransmissionManual
Tire7.00R16
Springs7/4+6
Dimension (LxWxH)5990x2200x2750 mm
Total Mass6350 kg
Rated Payload3000 kg
Kerb Weight3350 kg
Passengers3
Approach/Departure Angle23°/13°
Driving Type4x2
Wheelbase3360 mm
GearboxLC5T255M3
Front/Rear Track1640/1655 mm
Tire Number6+1 (spare)
Front/Rear Suspension1120/2095 mm
Rated Power68kw/92hp
Fuel TypeDiesel oil
Displacement2772 ml
Emission StandardEU 2
Cylinders4
Max Torque/Speed240N.m/1500-2900rpm
Rear Bucket4000x2000x500 mm
Dump FunctionOption
