10x6 Shacman Heavy Duty Wrecker 40T-50T Subframe
v1v2v3v4v5v6
Complete Truck · Wrecker

10x6 Shacman Heavy Duty Wrecker 40T-50T Subframe

  • Rated Power380hp
  • Engine Manufacturer/ModelWeiChai/WP10.380E22
  • Emission StandardEuro 2
  • Driving Type10*6 RHD/LHD
  • Total Mass42800Kg
  • Oil Tank300L aluminum tank

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 48388374

Overview

About this truck

The heavy duty integrated wrecker series offers capacities ranging from 30 to 50 tons. These vehicles feature a powerful 2- or 3-stage wrecker boom with a 66,000 to 111,000 lb. capacity, corrosion-resistant construction, and optional 3- or 4-stage underlifts designed for strength and performance. Available truck brands include ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, and IVECO with Euro 2, 3, 5, or 6 emissions standards, right-hand or left-hand drive configurations, and axle options from 4x2 to 8x8. Main features include dual planetary winches (15-25 tons each, totaling 30-50 tons), underlift capacity up to 28 tons with tow rates exceeding 56 tons, optional remote control, side toolboxes, and optional front legs and side pullers.

Specifications

Technical parameters

Product NameIntegrated Wrecker Truck
Transmission TypeManual
Dimensions (L X W X H) (mm)Customs Made
ConditionNew
SubframeEquipped
Main Winch20/25 Tons, 2 Pcs
Underlift3 Sections, Optional 4
Underlift Tow Rating25 Ton/50 Tons
OperationBoth Sides Manual
Remote ControlOptional
Warranty2 Year
Name10x6 Shacman Wrecker Truck
Dimension (LxWxH)11950x2550x3950 (mm)
Total Mass42800Kg
Rated Payload25000Kg
Kerb Weight17800Kg
Passenger3
Manufacture/ModelShacman
Driving Type10*6 RHD/LHD
Wheel Base2100+3175+1400+1400 mm
Gearbox10JSD180+QH50, ten speed forward and two reverse, manual
Tyre12.00R20
The Number of Tyre14+1(spare tyre)
Frame850x300(8+5+8)
AxlesFront 9.5 tons and rear 16 tons, MAN
Oil Tank300L aluminum tank
Engine Manufacturer/ModelWeiChai/WP10.380E22
Rated Power380hp
Fuel TypeDiesel oil
Displacement/Capacity9726ml
Emission StandardEuro 2
CylinderStraight/6/turbo charge/intercooling/watercooling/direct injection
Max. torque1600N.m
Velocity2200rpm
Underlift Retracted Lifting Capacity25000
Underlift Retracted Length1746
Underlift Extended Lifting Capacity7310
Underlift Extended Length3110
Underlift Tilt-10
Towing Capacity50
Boom Retracted Lifting Capacity (45)30
Boom Extended Lifting Capacity (45)8
Max. Lifting Tilt33
Max. Lifting Height7022
Main Winches Quantity2
Pulling Power15
Winch TypePlanetary
Steel Wire Length45
Steel Wire Diameter18
More models

You may also compare

Already have a chassis?

We also build the recovery equipment on its own — underlift booms, rotators, flatbed carrier beds, tow bars and complete kits, shipped ready to mount on the chassis you already run. Many buyers pay far less import duty this way than on a finished truck.

Our recovery-equipment site: itruckrecovery.com
See wrecker bodies & kits →
Interested in this model? —
we'll confirm specs and quote in 24 h.
