6000-8000 Liter Dongfeng Vacuum Truck Suction Sewage Truck
v1v2v3v4v5v6v7v8
Complete Truck · Vacuum Truck

6000-8000 Liter Dongfeng Vacuum Truck Suction Sewage Truck

  • Rated Power100 kW/135 hp
  • Engine ModelYC4E135 33
  • Emission StandardEU 3
  • Driving Type4x2
  • Total Mass12,000 kg
  • Sewage Tank Volume8,000 liters

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: 50544605

Overview

About this truck

This sewage suction truck represents a specialized environmental sanitation vehicle engineered for collecting, transferring, and cleaning liquid waste transportation. The cleaning and suction truck has the functions of flushing, dredging, suction, and reverse discharge. The vehicle operates on siphon principles: as air is extracted from the tank, atmospheric pressure forces sewage through intake hoses; compressed air subsequently forces contents through discharge ports. It is suitable for collecting and transporting liquid substances such as feces, mud, crude oil, etc. The unit emphasizes rapid operational speed, substantial capacity, and convenient transport capabilities for municipal and industrial applications.

Specifications

Technical parameters

Model NumberCL5120GXW6HQ
Dimension (LxWxH)7000x2350x3000 mm
Total Mass12,000 kg
Rated Payload5,720 kg
Kerb Weight6,140 kg
Passengers3
Approach/Departure Angle17/10 degrees
Driving Type4x2
Wheelbase3800 mm
Gearbox6TS55
Front/Rear Track2060/1855 mm
Tire Model7.50R16
Number of Tires6+1 (spare)
Front/Rear Suspension1370/2710 mm
Engine ModelYC4E135 33
Rated Power100 kW/135 hp
Fuel TypeDiesel oil
Displacement/Capacity4,257 ml
Emission StandardEU 3
Cylinders4
Max. Torque/Speed392 N.m/1,700 rpm
Velocity2,800 rpm
Sewage Tank Volume8,000 liters
Vacuum Suction PumpSK-12
Color/LogoCustomizable
