Isuzu 4x2 16cbm Compressed Garbage Truck
v1v2v3v4v5v6
● In stock
Complete Truck · Garbage

Isuzu 4x2 16cbm Compressed Garbage Truck

  • Chassis BrandIsuzu
  • Rated Power300 hp
  • Engine Model6HK1-TCG60
  • Emission StandardEuro 3
  • Driving Type4x2, LHD
  • Total Mass23800 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: GT-16ISU

Overview

About this truck

The Isuzu 4x2 16cbm compressed garbage truck is built on a reliable Isuzu chassis with a 300 hp engine and 8-speed manual gearbox. Its 16 cbm Q355 steel container and rear loading design handle 240 L, 660 L, and 1100 L bins efficiently. The truck features a one-and-half row cabin with A/C and both cab and manual side operation for flexible use. It is a new unit with CCC certification, available for quick delivery.

Specifications

Technical parameters

Chassis BrandIsuzu
Chassis ModelQL5220GX
Driving Type4x2, LHD
Wheelbase4500mm
Engine Model6HK1-TCG60
Rated Power300 hp
Emission StandardEuro 3
Fuel TypeDiesel
Gearbox8-speed manual
Tyre385/65R22.5
CabinOne-and-half row, A/C
Total Mass23800 kg
Kerb Weight11000 kg
Rated Payload12800 kg
Dimension (L×W×H)8900x2550x3200 mm
Max Speed95 km/h
Container Capacity16 cbm
Box MaterialQ355
Loading TypeRear loading
Garbage Can240 L / 660 L / 1100 L
OperationCab / Both sides manual
Remote Control1
ConditionNew
Warranty1 Year
