Isuzu 4x2 3.2 Ton Telescopic Boom Truck Mounted Crane
v1v2v3v4v5
Complete Truck · Crane Truck

Isuzu 4x2 3.2 Ton Telescopic Boom Truck Mounted Crane

  • Chassis BrandIsuzu
  • Rated Power120 hp
  • Engine Model4KH1CN6LB
  • Emission StandardEuro 6
  • Driving Type4x2, LHD
  • Total Mass7360 kg

Chassis, capacity, configuration, emission and LHD/RHD all customizable. Model code: ISU-CR-3200

Overview

About this truck

The Isuzu 4x2 truck mounted crane combines a reliable Isuzu chassis with an XCMG SQS68 telescopic boom crane, offering a maximum lifting capacity of 3200 kg. Its double-row crew cab provides comfortable seating for the operator and crew, while the 3500 kg payload and 3470 mm cargo body support efficient transport of goods and equipment. Powered by a 120 hp Euro 6 diesel engine and a 5-speed manual gearbox, this crane truck is suitable for a variety of lifting and delivery tasks.

Specifications

Technical parameters

Chassis BrandIsuzu
Chassis ModelQL1070BUKWY
Driving Type4x2, LHD
Wheelbase3815 mm
Engine Model4KH1CN6LB
Rated Power120 hp
Emission StandardEuro 6
Fuel TypeDiesel
Gearbox5-speed manual
Tyre7.00R16
CabinDouble row (crew cab), A/C
Total Mass7360 kg
Kerb Weight3860 kg
Rated Payload3500 kg
Dimension (L×W×H)6920×2150×3050 mm
Max Speed95 km/h
Crane BrandXCMG
Crane ModelSQS68
Crane TypeTelescopic boom
Max Lifting Capacity3200 kg
Working Radius5.5 m
Lifting Height6.8 m
Boom Sections2 sections
OutriggersH-type
Cargo Body Dimension3470×2050×380 mm
ConditionNew
Warranty1 Year
